GOBEL GBRK-4850M 48V 50Ah Rack Lithium LiFePO4 Battery Module

Product Specification:

Brand Name:

GOBEL, OEM&ODM

Model Number:

GBRK-4850M

Nominal Voltage:

48V (@25℃)

Nominal Capacity:

50Ah (@25℃)

Nominal Energy:

2.5Kwh (@25℃)

Cycle Life:

>6000times

Communication interface:

RS485、RS232、CAN(Optional)

Communication:

SMA、 Growth att、 Voltronic Power、 Solis、 Solax、 Sungrow、 Sofar、 Goodwe etc.

Warranty:

12 years for machinery warranty

Product Description

Our Energy Storage Solutions: GOBEL in China, GOBEL Lithium Iron Phosphate Batteries are a complete energy storage system. The integrated Battery Management System (BMS) monitors and regulates each cell in the battery bank to provide perfectly balanced charging and discharging. The lithium-ion solar battery system is contained in a rugged metal enclosure – Quick and easy installation.





GOBEL GBRK-4850M 48V 50Ah Rack Lithium LiFePO4 Battery Module

  • Lifepo4 battery pack is a new environmentally friendly backup power system focused on short-time and high-rate discharge scenarios.
  • The environmentally friendly lithium-ion battery is configured with high-performance BMS. BMS with imported chips and MOS, with balancing function and dual protection, has a wide range of performance and application advantages compared with conventional batteries.
  • Have low internal resistance and high, flat voltage characteristics during strong current discharge, which ensures a wider application field.
  • All these are Hi-quality cells, with Longer cycle life, and full inspection before shipment.



Product Performance

  • Vertical industry integration ensures more than 8500 cycles with 90% DoD.
  • The compact and fashionable design fits in your sweet home environment.
  • Modular design gives the end customers the power of choice of capacity.
  • Compatible with most of the available Hybrid inverters.
  • Simple buckle fixing minimizes the installation time and cost.
  • Safety Cert. TüV CE UN38.3 IEC.

Product Specifications:
ModelGBRK-48050
Battery Cell TypeEVE, BYD, CATL etc.
Nominal Voltage48V
Nominal Capacity5AH
Nominal Energy2.5KWH
Max. Continous Charge Current @25℃50AH
Max. Pulse charge Current @25°C,10s60AH
Max. Continous Discharge Current @25℃50A
Max. Pulse Discharge Current @ 25°C, 10s60A
DC Resistance≤50mΩ
Full Charged Voltage52V
Discharge Cut-off Voltage40V
Operate Temperature Charge: 0˚C~55˚C;
Discharge: -20˚C~60˚C;
Storage: -20˚C~45˚C
Humidity (non-condensing)Max. 95%
Dimension (mm)442mm*440mm*222.5mm
Weight (KG)30KG
Terminal TypeScrew termina
Cover Sealing typeScrew / gel sealing optional
Cycle life
>6000times
Service Life15 years
Warranty10 years
LCD Screen DisplayOptional (Show voltage V, Power %)
BluetoothOptional (Bluetooth with mobile APP)
Series and Parallels FunctionAvailable to make in series and parallels to get 24V, 36V, 48V



Energy Storage
–Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
–Telcom Base / CATV system / Computer Server Center / Medical Instrument / Military Equipment
Other Applications
–Security and Electronics / Mobile POS, Mining Light / Torch / LED Light / Emergency Light
–RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
–LED Backup / Engine Starting Battery, etc.







Cooperative and Adapted Companies

GOBEL Certificate

Factory Show

High-Quality Cells

Battery Test

Production Line

Battery Cabinets

The Stock

Delivering

Shipping and Payment

FAQ

Q: What is special about lithium batteries?

A: With high energy density, it has reached 460-600Wh/kg, which is about 6-7 times that of lead-acid batteries. Long service life, the life span can reach more than 6 years. Lightweight, the weight is about 1/5-6 of the lead-acid product under the same volume.

Q: What is a lithium battery used for?

A: Lithium battery used for power and energy storage. Like emergency power backup or UPS. Dependable electric and recreational vehicle power, golf cart, reliable and light-weight marine, solar power storage, solar house, Small processing factory, surveillance or alarm systems in remote locations.

Q: Are your batteries safe?

A: Our batteries are safe. All GOBEL batteries use the safest and most stable components, including a LiFePO4 cathode and a built-in Battery Management System (BMS). The BMS protects the cells against excessively high or low voltages, high currents, short circuits, and excessive heat or cold. These are the most common causes of battery failures, and we have taken every precaution to mitigate these risks in all of our batteries.

Q: Can it be series or parallel for use?

A: Yes sir, it can support max. 15 in parallel connection for use, Max 150kwh storage box

Q: What is a lithium battery used for?

A: Lithium battery used for power and energy storage. Like emergency power backup or UPS. Dependable electric and recreational vehicle power, golf cart, reliable and light-weight marine, solar power storage, solar house, Small processing factory, surveillance or alarm systems in remote locations.

Q: Can these battery packs be compatible with my inverter? do you have a company list of the inverter which is compatible?

A: Yes sir, our battery pack can compatible with most brands of inverters on the market, such as Deye, MUST, SMA, Growatt, Solax, Solis, Sungrow, Sofar, Voltronic, Sorotec, Studer, etc. contact us and let me tell you more.
